Ex Circuit Breakers Module

Circuit breakers that provide reliable protection for conductors in hazardous areas offers a variety of different circuit breakers designed for specific intended purposes in hazardous areas, each and every one of which provides outstanding protection against overloading and short-circuiting.
Delvalle produces various types of circuit breaker, which protect your systems against overloading and short-circuiting. They are designed for rated currents of 0.5-40A and can switch 6 or 10 kA.

Ex Circuit Breakers Module · Atex DelvalleAtex Delvalle

This product has the following certificates

  • Logo Atex · Atex Delvalle
  • Logo IECEx · Atex Delvalle

Description

Circuit breakers that provide reliable protection for conductors in hazardous areas offers a variety of different circuit breakers designed for specific intended purposes in hazardous areas, each and every one of which provides outstanding protection against overloading and short-circuiting.
Delvalle produces various types of circuit breaker, which protect your systems against overloading and short-circuiting. They are designed for rated currents of 0.5-40A and can switch 6 or 10 kA.

  • Zones 1 and 2.
  • Rated voltage: 230V / 400V, 50 / 60Hz; 250V DC.
  • Rated current: Max. 40A.
  • Rated ON/OFF capacity: 6kA, 1 0kA.
  • Trip character: C, D characteristic curve.
  • Aux.contact: 250V/400V, 50/60Hz, 4A; ll0V DC 0.5A.
  • Terminals:
    • Main contacts 1 - l0mm² (6 - l0mm² used in connection with compression lug).
    • Auxiliary contact 1 - 2.5mm².
  • Material of enclosure: unsaturated resin.

Regulations

  • Certificates number:
    • CML 19ATEX1299U
    • IECEx CML 19.0084U
  • Type protection:
    • II2G  Ex db eb IIC Gb
  • Standard:
    • Directive 2014/34/EU
      • EN IEC 60079-0:2018
      • EN 60079-1:2014
      • EN IEC 60079-7:2015+A1:2018
      • IEC 60079-0:2017
      • IEC 60079-1:2014-06
      • IEC 60079-7:2017
    • Ambient temperature:
      • -20ºC - +60ºC (IIC)
      • -40ºC - +60ºC (IIB)
    • Operating temperature:
      • -20ºC - +110ºC (IIC)
      • -40ºC - +110ºC (IIB)

    Applications

    Designed for installation in ‘Ex e’ enclosures in Zones 1 and 2 and as a protective and switching device.

    Custom Made Solutions
    We offer multiple solutions

    Ex Circuit Breakers Module · Atex Delvalle
    Do you need ATEX solutions?
    2024 product catalogues



    Customers also bought:
    Ex Magnetic Starter Module (Contactor+Thermorelay) · Atex DelvalleAtex Delvalle
    Delvalle Ex contactor/motor protection relay combination was designed for installation in ‘Ex e’...
    Ex Reversing Contactor Module · Atex DelvalleAtex Delvalle
    Delvalle contactors are compact components for Ex e enclosures in Zones 1 and 2 that you can really...
    Ex Residual Current Circuit Breaker Module · Atex DelvalleAtex Delvalle
    Delvalle residual current circuit breaker is a component for residual current monitoring and...
    Ex Motor Protection Module · Atex DelvalleAtex Delvalle
    Atex Delvalle offers various components that have been specially designed for protecting motors in...
    Ex Relay Module · Atex DelvalleAtex Delvalle
    Delvalle relays are versatile components for ‘Ex e’ enclosures in Zones 1 and 2 that you can...
    Ex Protection Relay Module · Atex DelvalleAtex Delvalle
    Atex Delvalle protection relays offer cost-effective overload protection for motors with adjustment...
    Ex Contactor Module · Atex DelvalleAtex Delvalle
    Delvalle contactors are compact components for ‘Ex e’ enclosures in Zones 1 and 2 that you can...
    Ex Timer Relay Module · Atex DelvalleAtex Delvalle
    Delvalle timer relays are versatile components for ‘Ex e’ enclosures in Zones 1 and 2 that you...
    Explosion - Proof Load Isolation Switch Module · Atex DelvalleAtex Delvalle
    Motor, load and control switches for hazardous areas. ...
    Ex Circuit Breakers Module · Atex Delvalle

    Sketches
