Home > Products > Ex Signal Lamp with Push Button Module Increased Security

Ex Signal Lamp with Push Button Module Increased Security

Delvalle explosion-proof signal lamp with button module increased security shall be used together with corresponding operation head and shall be mounted inside ‘Ex e’ enclosure conform to Atex and IECEx certifications.
Zones 0 (Ex ia IIC Ga), 1 and 2 and can be used in two available Ex marking and two low temperature ratings for option -40°C / -55°C.

Technical Downloads Product
011_modulo-de-pulsador-para-seguridad-intrinseca-luminoso-atex_atexdelvalle.67850b8e-10
Front mounting on rail
Rear mounting
Atex push buttons
CML 19ATEX1296U
IECEx CML 19.0081U
Ex ia IIC Ga
-55ºC to +55ºC (Ex ia IIC)
-40ºC / -55ºC (optional) to +90ºC
Directive 2014/34/UE
EN IEC 60079-0:2018
EN IEC 60079-7:2015+A1:2018
EN 60079-1:2014
EN 60079-11:2012
EN 60079-26:2015
IEC 60079-0:2017
IEC 60079-1 2014-06
IEC 60079-11:2011
IEC 60079-7:2017
Protection rating: IP20

Sketch:

product sketch
